Completely custom build your own Electric Carveboard
Write up to two colour choices in your order notes
Able to turn (Carve) tighter than anything else on the market, while being packed with the same high performance equipment as an electric mountainboard, this board offers a whole new riding experience!
Being able to fit Stickies, Gummies & Pneumatic Tyres (standard tyres up to 7″), this Carve Board is essentially 3 boards in 1, with each providing an entirely different road feel!
Carve Boards come as standard with a rear mounted Beast Battery Box, with choices between 6.2Ah, 12Ah & 16Ah. Rear mounting means that the deck doesn’t loose any of its flex or ‘pop’ while leaving space for 100% free foot placement
Motors come with a choice of single or twin motors, single motors are cheaper, around 1kg lighter & can reach the same top speed, however the twin motors provide a significant increase in grip, acceleration & braking, as well a reducing the running temperature of the motors
Long enough to feel substantial and stable beneath your feet at feet, while also remaining small enough to take on public transport
For Decks there’s a choice between the Carveboard Solid Deck and the Holy Pro with its cutouts and 150g reduced weight. Both have the same profile using 35 degree tips and measuring 850mm tip-tip
Trampa’s Electric Carve Board
We don’t offer credit on purchases at this time. However we are currently looking into offering a credit option in the very near future.
The Stripe Payment Gateway supports payments in 135 currencies. A currency conversion occurs if the selling currency differs from the paying currency.
Bear with us, this can take 10/20 seconds!
Globally renowned high quality motor controller
You will likely have come across VESC™ by now, it is very special in the field of Electronic Speed Controllers so we are very proud that our boards all come as standard with a VESC™ and VESC™ BMS.
VESC6 Mk6 HP – Quite simply a higher powered version of the VESC6 Mk6, with the same trusted reliability and ease of control. Why High Power? Because the mosfets in the HP allow more amps to run through.
VESC6 Mk6 – An incredibly reliable and high performing compact speed controller, used by over 2000 companies in many other applications across the world
VESC 6/75 – If you are using a 16s Battery Pack to power your mountainboard this controller will automatically be selected to handle the higher voltage.
We make battery packs for both Li-Po & Li-Ion cells.
The (S) stands for Series - adding cells in series increases voltage, The (P) stands for Parallel - adding cells in parallel increases capacity.
A higher voltage will take you faster and higher capacity will take you further. See the table below for further comparison:.
Battery Power
Battery Pack Cells Capacity Voltage at peak
12S Li-Po 12S 1P 20Ah 50.4V
16S Li-Po 16S 1P 20Ah 67.2V
12S 21700 Li-Ion 12S 7P Molicell P42A – 29.4Ah
Samsung 40T- 28AhMolicell P42A – 50.4V
Samsung 40T – 50.4V
Battery BMS, Enclosure & Charger
Battery Pack BMS Enclosure Charger Battery (+charger)
12S Li-Po In charger Classic or Massive Ultramat 18
UltraPower
£840 +VAT
16S Li-Po VESC BMS 16S Massive 16S 8A Li-ion £675 +VAT
12S 21700 Li-Ion VESC BMS Massive or Double Massive 12S 6A Li-ion
12S 12A Li-ion£574 + VAT
£609 +VAT
Li-Po: These cells are more expensive, however you may consider them worth it because they have less components and therefore provide easy plug and play capability as well as making it possible to do a quick battery swap. Li-Po cells also have a higher discharge performance than the Li-ion packs.
Li-ion: Individual cells means that you have a serviceable battery pack, swapping out only the individual cells should they be damaged. These cell packs require some electrical knowledge.
We suggest that if you have limited electrical knowledge that you choose Li-Po batteries for their ease.
